Conductor Material CCA Number of Strands 24/0.2mm Insulation Material Polyvinyl Chloride (PVC) Insulation Colour : RED/BLACK Electrical Characteristics: Nominal Conductor Resistance < 26.0 Ω/km Insulation Resistance > 100 MΩ.M Capacitance 82 pF/m ± 15 Voltage Rating 300/500V Test Voltage 2.5kV for 5 Minutes Physical Characteristics: Overall Diameter 1.5 x 3.6 ± 0.2mm Min. Bend Radius 15 x OD Temperature Rating -20°C to 70°C
